Product OverviewBEA MATRIX Loop Detector is a digital inductive single-channel vehicle detector designed for parking barrier control, motorized gates, doors, vehicle access control, and industrial control systems. For Abu Dhabi parking and gate automation sites, it helps detect vehicles through an installed ground loop and provides reliable presence detection for barrier opening, safety holding, or access control triggering. The BEA MATRIX range is available in single and dual-channel versions, with single-loop versions listed for 110–120 V AC and 12–24 V AC/DC power supply options. It uses automatic tuning, adjustable sensitivity, presence timing, and frequency settings to support stable vehicle detection.Key Features and Technical SpecificationsOfficial product range: BEA MATRIX2 Digital Inductive Loop SensorsProduct type: Single-channel inductive loop detectorSingle-loop model options: MATRIX2-S110 CUSTOM and MATRIX2-S12-24 CUSTOMApplication: Parking barrier control, motorized gates and doors, vehicle access control, and industrial control systemsTechnology: Inductive loopTuning: AutomaticDetection mode: PresencePresence time: 1 minute to infinity, with 250 stepsPulse time output: 100 ms or 500 msInductance range: 20 µH to 1000 µHFrequency range: 20 kHz to 130 kHzFrequency steps: 4 for single loopSensitivity: 0.005% to 0.5%, with 250 stepsReaction time: 25 ms for single loopSetup time at power on: 8 seconds maximum per channelSetup time after configuration: 2 seconds maximum per channelPower supply options, depending on model: 12–24 V AC/DC ±10%, 230 V AC ±10%, or 115 V AC ±10%Power frequency: 48 to 62 HzPower consumption: < 2.5 WTemperature range: -30°C to 70°CDegree of protection: IP40Output relays: 2 free-potential change-over contact relaysMaximum contact voltage: 230 V ACMaximum contact current: 5 A resistiveLED indicators: 1 green power LED and red loop status LEDsProtection features: Loop insulation transformer, Zener diodes, and gas discharge clampingConnection: Standard 11-pin round connector 86CP11Dimensions: 77 mm × 40 mm × 75 mmWeight: < 200 gAutomatic sensitivity boost: Available as ASB function in configuration settingsContinuous temperature adjustment: Not specified by manufacturerUse CasesAutomatic parking barriersParking entrance and exit lanesResidential gate automationVilla gate safety loopsCommercial vehicle access controlIndustrial gates and barriersMotorized doors and shuttersWarehouse vehicle entry pointsLong-presence vehicle detection applicationsCompatibility and Installation NotesThe BEA MATRIX Loop Detector is compatible with automatic barriers, gate operators, motorized doors, and access control panels that accept relay contact input from an inductive loop detector. Installation requires a correctly cut ground loop, suitable loop cable, proper feeder twisting, waterproof cable junction protection, and correct wiring to the 11-pin socket. BEA states that power must be shut off before wiring and that traffic should be controlled during testing to prevent unexpected gate or barrier movement. Professional installation is recommended to set frequency, sensitivity, presence time, relay mode, and loop geometry correctly; review the official BEA MATRIX2 user guide before installation.Packing Includes1 × BEA MATRIX single-channel loop detectorWhy Buy from POWERgate Abu DhabiPOWERgate Abu Dhabi supplies reliable parking barrier and gate automation products with local support for access control projects. We help buyers confirm voltage, loop detector type, relay compatibility, and installation requirements before purchase.Buy BEA MATRIX Loop Detector today from POWERgate abu dhabi. Call/WhatsApp: 971 50 88 44933 or email us: [email protected].
