Description Specification Details Network Ports 4, 10/100Mbps; RJ45 port; Max. 30W Output of Single PoE Port Uplink Ports 2, 10/100Mbps; Transmission Distance: Default: 0-100m Switch Capacity 1.2Gbps (non-blocking) Forwarding Rates 0.1488 Mbps/port PoE Standard IEEE802.3/802.3u/802.3x PoE Power Supply 1/2( ), 3/6(-) Transmission Distance 0-100m/100Mbps or Max. 250m/10Mbps via Cat.5e or more under Extend mode MAC Address List 2k Lightning Protection Support PoE Power Budget 48W ESD Protection Air discharge: 8KV Contact discharge: 6KV Power Consumption <5W LED Light Green light off: Link is disconnected Green light on: Link is connected Green light flash: Data Transmitting Power Source Built-in Power Supply, Input: 100-240V AC, 50/60Hz Power Light Light on: Powering Light off: No Power Working Temperature -10°C ~ 50°C Humidity 5%-95%, non-condensing Storage Temperature -40°C ~ 70°C Dimensions 200mm x 118mm x 44mm (LxWxH)
